PendoTECH Conductivity and Temperature Monitor
Reads conductivity and temperature from up to two sensors.
Overview
Features
- 400ohms sourcing with maximum load
- 0.1% of full scale accuracy
- 4-20mA analog outputs
- D15 male, with screw terminal adaptor
- 2 conductivity with 0-100mS range
- 2 temperature with 0-70°C range
- RS-232 output included for data collection to a PC
- Performs temperature normalization to 25°C
- NEMA 4X certified front panel
- RoHS and REACH Compliant
- CE Mark EN613261:2013; EN61010-1:2010
What's in the Box
- Conductivity Monitor Unit
- Connector for field wiring
- Power Supply with country-specific plug blades
- 10ft cables for connection of conductivity sensors
Description
PendoTECH Conductivity and Transmitter Monitor is designed to read conductivity and temperature from up to two sensors, with the ability to read just the temperature. Sensors are connected to the monitor via 4-20mA analog outputs, two for temperature and two for conductivity. Additionally, the monitor also features temperature compensation that normalizes conductivity readings to 25°C, as well as an RS-232 output for PC data collection.
