PendoTECH Small Scale Conical Bottom Process Vessel
140ml or 600ml tank with low point drain, lid, 2 dip tubes, 3-way stopcock, and stir bar.
Overview
Features
- 140ml or 600ml capacity
- Polysulfone, nylon, and TPV contact surfaces
- Includes 2 dip tubes, 3-way stopcock, and stir bar
- Transparent design with graduation marks
- Stir bar locator in the bottom for process mixing
- Compatible with many chemicals, including sodium hydroxide
- Conical base and low-point drain that minimizes liquid hold-up
Description
PendoTECH Conical Bottom Vessel is designed for use at atmospheric pressure and features a conical bottom with low point drainage. These features help enable high-concentration factors in a tangential flow filtration (TFF) process because of the unit's Low Holdup Volume. This unit includes a 140ml or 600ml tank with a low point drain, lid, 2 dip tubes, 3-way stopcock, and a stir bar.
PentoTECH Lab Scale Process Vessel tanks are constructed with transparent polysulfone that enables viewing of contents and it is also compatible with NaOH that is often used during the sanitization process. At the base of the tank, a female luer lock outlet is included so that the unit can be easily integrated into the process flow path. At the top of the vessel, the lid can be easily inserted. The lid has adjustable collars and includes 3 holes - two for dip tube placement and one for venting.
